Overview
LD490
The All Safe Height Safety sliding roof access hatches are uniquely designed to provide safe and easy access for personnel and equipment from inside the building.
- Available with corresponding flashing kit
- Configurations for both corrugated and tray deck roof profiles
Specification
Materials
- Zincalume sheet metal
- Aluminium frame construction
Dimensions
LD494C:
- Opening clearance: 1000 x 800mm
- 1365 (L) x 1165 (W) x 170mm (H)
LD494T:
- Opening clearance: 1000 x 800mm
- 1305 (L) x 1105 (W) x 230mm (H)
LD497.1000:
- Opening clearance: 1000 x 722mm
- 1400 (L) x 1200mm (W)
LD498.1200:
- Opening clearance: 1200 x 920mm
- 1600 (L) x 1400mm (W)
LD494T:
- Opening clearance: 1400 x 920mm
- 1900 (L) x 1400mm (W)
Weight
24kg
Compliance
All Safe Height Safety Solutions roof access hatches are designed to conform with requirements of the Australian & New Zealand Standards AS/ NZS 1657:2018 and relevant codes of practices and guidelines.
Key features
1. Two door configurations
The roof access hatch comes in either sliding or hinged door access, to suit different size requirements.
2. Flashing options
The roof access hatch has multiple flashing options to suit either tray deck or corrugated deck roof types.
3. Construction
Manufactured with an aluminium frame and zincalume shell, proving corrosion resistance and improving the products longevity.
4. Weatherproof
The insulated double skin limits noise and thermal transfer, and the EPDM weatherproof seal provides protection from the elements.
5. Easy to operate
Designed with precision steel bearing slides and gas strut assist, making use and operation easy.
6. Locking function
Includes a one hand operated push lock with keys to secure the hatch when not in use.
